The Anritsu MS2711D spectrum analyzer is a wide band, very sensitive receiver. It works on the principle of "super-heterodyne receiver" to convert higher frequencies (normally ranging up to several 10s of GHz) to measurable quantities. The received frequency spectrum is slowly swept through a range of pre-selected frequencies, converting the selected frequency to a measurable DC level (usually logarithmic scale), and displaying the same on the CRT of the Anritsu MS2711D. The CRT displays received signal strength (y-axis) against frequency ( x-axis).
Some applications for Anritsu MS2711D Spectrum Analyzers include Site Monitoring: Verify that the frequency and signal strength of your transmitter is accurate. Interference: Before a system is installed you use a Anritsu MS2711D spectrum analyzer to verify that the frequencies (you plan to use) are not occupied or if the presence of a very strong signal will interfere with your new setup. Interference can be created by a number of different situations.
Other tests that utilize the Anritsu MS2711D spectrum analyzer features include antenna isolation, co-channel interference, adjacent channel power, occupied bandwidth, intermodulation, microwave or satellite antenna alignment, and characterization of components.
| KEY FEATURES |
| Handheld, battery-operated design |
| Built in pre-amplifier (standard) |
| Lightweight at only 4.9 lbs |
| Noise Level < -135 dBm typical |
| Quick Zoom-in, Zoom-out display in 1-2-5 sequence |
| RBWs: 100 Hz to 1 MHz in 1-3 sequence |
| VBWs: 3 Hz to 1 MHz in 1-3 sequence |
| Automatic, manual, and dynamic attenuator control |
| Amplitude Accuracy +/- 0.5 dB typical |
| Dedicated One-button measurements |
| Trace Averaging |
| Reference Level Offset |
| Trace Overlay |
| Store up to 15 measurement test set-ups |
| Save up to 200 measurement traces |
| Alphanumeric labeling of saved measurements |
| Automatic time and date stamp of saved data |
| Rechargeable/field-replaceable battery |
| 6 Markers, limit lines and segmented limit lines |
| 50-ohm Interface standard (75-ohm interface capability - instrument internally corrects for adapter loss) |
| RS232 Interface |
| Built in AM, FM and SSB demodulation |
| Transmission Measurement, 25 MHz to 2.5 GHz (option 21) |
| Power Meter (option 29) |
| Frequency Converter Controller Module available (option 6) for use with Anritsu FCN4760 4.7 to 6.0 GHz Down Converter |
| SPECIFICATIONS |
|
| Model: MS2711D Handheld Spectrum Analyzer Overview |
|
| Model: | Description |
| MS2711D | Handheld Spectrum Analyzer: 100 kHz to 3 GHz |
| OPTIONS |
|
| Option 19 | High Accuracy Power Meter (sensor not included) |
| Option 21 | Transmission Measurement |
| Option 25 | Interference Analyzer (best with directional antenna) |
| Option 27 | Channel Scanner |
| Option 29 | Power Meter |
| SPECIFICATIONS |
|
| Handheld Spectrum Analyzer Overview |
|
| Model | Description |
| MS2711D | Handheld Spectrum Analyzer: 100 kHz to 3 GHz |
| MS2711E | Spectrum Master Handheld Spectrum Analyzer: 9 kHz to 3 GHz |
| MS2712E | Spectrum Master Handheld Spectrum Analyzer: 9 kHz to 4 GHz |
| MS2713E | Spectrum Master Handheld Spectrum Analyzer: 9 kHz to 6 GHz |
