Keysight Technologies N9075EM0D

The Mobile WiMAX measurement application transforms the X-Series signal analyzers into standard-based Mobile WiMAX transmitter testers by adding fast one-button power and modulation measurements to help you design, evaluate, and manufacture your Mobile WiMAX devices, based on IEEE 802.16e-2005 and WiBro. When the Keysight Technologies, Inc. N9030A PXA or N9020A MXA signal analyzer has optional baseband IQ inputs, Option BBA, each of the RF and analog baseband IQ signals of Mobile WiMAX can be measured to compare signal quality.

The X-Series signal analyzers along with the Mobile WiMAX measurement application, perform transmitter measurements on BS and MS devices in time, frequency and modulation domains. Mobile WiMAX signals with zone types PUSC, FUSC, OPUSC, OFUSC, and AMC can be analyzed. Additionally, modulation analysis can be done on matrix A signals and pilotbased modulation analysis can be done using a single input on matrix B signals.

Key Features:

• Mobile WiMAXTM RF transmitter measurements
• Single-channel matrix A modulation analysis and pilot-based matrix B (wave 2) analysis
• One-button tests with pass/fail limits per Mobile WiMAX standard
• Hardkey/softkey manual user interface and SCPI remote user interface
• Built-in context sensitive help
• Flexible licensing provides the option of using perpetual or time based licenses with one or multiple signal analyzers
