Keysight Technologies DSOX1EMBD

Configure Unit

Available to Buy Online

View Configurations

Embedded Serial Triggering and Analysis (I2C, SPI, RS-232)

Model

DSOX1EMBD

Product Family

Oscilloscopes & Logic Analyzers

Manufacturer

Keysight Technologies

Configured models contain the following attributes:

Oscilloscopes & Logic AnalyzersOscilloscopes < 1GHz

Configurations

Key Specs

Product Overview

Resources

Let us help you with your exact configuration

Please use 'Get Quick Quote' or ‘Configure Unit’ and we’ll contact you and quote for your exact need.

Configure Unit

You can also get in touch, if you prefer, and our experts will be able to guide you with the right application and procurement solution for this product.

Product Overview

The I²C, SPI, and UART/RS-232 serial decode option for InfiniiVision 1000 X-Series oscilloscopes (DSO models) displays responsive, time-aligned, on-screen decode of Inter-Integrated Circuit (I²C), 3-wire Serial Peripheral Interface (SPI), and UART/RS232 serial communication buses. Because it is hardware-based, this option provides the fastest throughput solution for triggering on and analyzing I²C, SPI and UART/RS-232 serial buses found in a wide variety of embedded designs.

DSOX1EMBD works with InfiniiVision 1000 X-Series models DSOX1102A and DSOX1102G.
D1200EMBA works with InfiniiVision 1000 X-Series models DSOX1204A and DSOX1204G.

Key Features & Specifications

The fastest throughput oscilloscope solution for triggering on and analyzing I²C, SPI and UART/RS-232 serial buses

Support for the I²C serial protocol

Support for the 3-wire SPI serial protocol

On-screen serial decode time-correlated with the serial data waveforms

Protocol trigger and hardware-based protocol decode
